LM2587 DC DC-DC Boost Converter 3-30V Step up to 4-35V Power Supply Module MAX 5A Board

Product description
Specifications:
1.Module Properties:non-isolated step-up module(Boost)
2.Rectification: Non-Synchronous Rectification
3.Input voltage: DC 3-30V (Note: The boost module input voltage can not be higher than
the output voltage,the output stable at the set value)
4.Output voltage: DC 4-35V
5.Output current: 5A MAX, (15mA unload)
6.Conversion efficiency: 92% (MAX)
7.Switching frequency: 100KHz
8.Output ripple: 50mV (MAX)
9.Load regulation: ± 0.5%
10.Voltage regulation: ± 0.5%
11.Operating Temperature: -40 °C to +85 °C
12.Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease)

Package Included:
1 x LM2587 Module
