Raspberry PI 4B 8GB

Overview:



Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi series of computers. Compared with the previous generation Raspberry Pi 3 Model B +, it has achieved breakthrough growth in processor speed, multimedia performance, memory and connectivity, while maintaining backward compatibility and similar power consumption. For end users, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.



The main features of this product include a high-performance 64-bit quad-core processor, up to 4K resolution supporting dual displays, up to 4Kp60 hardware video decoding, up to 8GB of RAM, dual bandwidth 2.4/5.0 GHz wireless LAN, Bluetooth 5.0, Gigabit Ethernet, USB 3.0 and PoE functions (via separate PoE HAT add-ons).



The dual-band wireless network card and Bluetooth have a modular qualification certificate, allowing the board to be designed as a high-end product to significantly reduce compatibility testing, increase costs, and shorten time to market.



specification

Processor: Broadcom BCM2711, quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz

Connectivity:

2.4 GHz and 5.0 GHz IEEE 802.11b/g/n/ac wireless LAN, Bluetooth 5.0, BLE Gigabit Ethernet

2 USB 3.0 ports

2 USB 2.0 ports.

Video and sound:

2 mini HDMI ports (support up to 4Kp60)

2-channel MIPI DSI display port

2-channel MIPI CSI camera port

4 pole stereo audio and composite video ports

Multimedia:

H.265 (4Kp60 decoding);

H.264 (1080p60 decoding, 1080p30 encoding);

OpenGL ES, 3.0 graphics

SD card support: Micro SD card slot for loading operating system and data storage

Environment: Operating temperature 0–50ºC
